In the intricate world of modern interior design, lighting is a paramount element that shapes ambiance, enhances visual aesthetics, and fosters a sense of well-being. Our esteemed company, a forerunner in the domain of dimmable recessed lighting manufacturing, meticulously crafts innovative solutions that effortlessly integrate into any architectural vision, granting unparalleled illumination control and aesthetic harmony. We pride ourselves on our commitment to excellence, reflected facet of our products—from the impeccable craftsmanship to the integration of cutting-edge technologies.
In the realm of modern interior design, lighting plays a pivotal role in creating ambiance, enhancing visuals, and promoting overall well-being. Our esteemed company, as a leading dimmable recessed lighting manufacturer, takes pride in crafting innovative solutions that seamlessly blend into any architectural masterpiece, offering unparalleled control over illumination and aesthetics. Our commitment to excellence is evident in every detail of our products, from the meticulous craftsmanship to the use of cutting-edge technology.
Products Information
Code
TS-DO10WZ
TS-DO15WZ
TS-DO20WZ
TS-DO30WZ
Rated Power
10W
15W
20W
30W
Cut-Out
D 75MM
D 95MM
D 120MM
D 160MM
Input Current
45mA@220V
68mA@220V
91mA@220V
136mA@220V
Lumens
1000lm +/-5%
1500lm +/-5%
2000lm +/-5%
3000lm +/-5%
Beam Angle
24°
24°
24°
24°
Size
D87xH40MM
D106xH45MM
D135xH55MM
D175xH65MM
Common Data
Products Name
Dimmable recessed lighting manufacturer
Body Color
Sandy White / Sandy Black
Materials
Aluminium Body + Lens
IP Rate
IP44
Add Honeycomb
Not Available
Anti glare
Yes
UGR
<19
Flicker Free
Yes
Installation
Recessed Type
Certificates
CE-EMC, CE-LVD, RoHS, FCC, C-tick
Electrical Data
Working Voltage
220-240VAC / 100-277VAC
Frequency
50/60Hz
Power Factor(PF)
>0.9
Driver Brand
Lifud / Eaglerise / Kegu / Philips / Osram
Dimmable
Non-DIM / TRIAC / 0-10V / Dali / Push Dimming
Total Harmonic Distortion(THD)
≤15%
Lighting Source Data
Color Temperature
27/30/40/45/50/60K Warm White/Neutral White/ Day White/ Cool White
